Reciprocating (Piston) Air Compressors
Reliable, Cost-Effective & Built for Performance
In industries where dependable compressed air is essential, Reciprocating (Piston) Air Compressors remain one of the most trusted and proven technologies. Known for their rugged construction, affordability, and high-pressure capabilities, piston compressors are widely used across workshops, manufacturing units, and specialized industrial applications.
Loitha Air Compressors offers a complete range of high-performance piston compressors designed to deliver consistent air output, long service life, and energy-efficient operation. From compact workshop units to heavy-duty industrial machines, Loitha ensures reliability in every application.
What is a Reciprocating (Piston) Air Compressor?
A reciprocating air compressor uses a piston-driven mechanism to compress air within a cylinder. As the piston moves, air is drawn in, compressed, and delivered at the required pressure.
These compressors are ideal for:
- Intermittent and medium-duty applications
- High-pressure requirements
- Cost-sensitive operations
Loitha Piston Compressor Range
High-Pressure Piston Compressors (≥ 15 Bar)
Engineered for demanding industrial applications requiring high pressure and consistent output.
Applications
- PET Bottle Blowing
- Gas Compression (CNG, Industrial Gases)
- High-pressure testing
Key Features
- Stable high-pressure performance
- Heavy-duty construction
- Reliable operation in extreme conditions
Low-Pressure Industrial Compressors (< 15 Bar)
The backbone of manufacturing industries where continuous air supply is essential.
Applications
- Fabrication units
- Engineering workshops
- General industrial use
Key Features
- Consistent airflow
- Energy-efficient operation
- Durable design for daily use
Professional & Workshop Series
Compact, portable, and powerful compressors designed for small-scale and mobile applications.
Applications
- Automotive garages
- Service centers
- DIY and maintenance work
Key Features
- Easy mobility
- Low operating cost
- Plug-and-use functionality
Oil-Free Piston Air Compressors
For industries where air purity is critical, Loitha offers Oil-Free Reciprocating Compressors that deliver completely contamination-free air.
Ideal for:
- Medical & Dental Applications
- Pharmaceuticals
- Food & Beverage Processing
- Electronics Manufacturing
Benefits:
- Zero oil contamination
- Compliance with strict hygiene standards
- Safe for sensitive applications
Key Features & Advantages
Robust Cast-Iron Construction
Heavy-duty cast-iron cylinders and components ensure long life and reliable performance even in harsh environments.
High Reliability with Low Maintenance
Simple mechanical design reduces breakdowns and makes maintenance easy and cost-effective.
Energy-Efficient Performance
High-efficiency motors optimize power consumption while delivering consistent compressed air.
Slow-Speed Operation
Low RPM design reduces wear and tear, increasing machine life and minimizing downtime.
Efficient Cooling System
Deep-finned cylinders and high-performance cooling fans prevent overheating during continuous operation.
Low Life-Cycle Cost
Loitha compressors are designed for long-term savings with minimal maintenance and consistent efficiency.
Technical Parameters
| Model | Motor Power | Working Pressure | Free Air Flow | Valve-1 | Valve-2 | Tank Size | Electricity | ||
|---|---|---|---|---|---|---|---|---|---|
| 50Hz | Hp | Bar g | Psi g | cfm | DN | DN | in Ltr | in Inches | (V/ph/Hz) |
| LSP-0.5A | 0.5 | 4 | 58 | 2.7 | 1/4″ | – | 60 | 12X32 | Single Phase |
| LSP-1A | 1 | 6 | 87 | 3.35 | 1/4″ | – | 90 | 14X34 | Single Phase |
| LSP-1A | 1 | 6 | 87 | 3.35 | 1/4″ | – | 130 | 16X40 | Single Phase or 3Phase |
| Model | Motor Power | Working Pressure | Free Air Flow | Valve-1 | Valve-2 | Tank Size | Electricity | ||
|---|---|---|---|---|---|---|---|---|---|
| 50Hz | Hp | Bar g | Psi g | cfm | DN | DN | in Ltr | in Inches | (V/ph/Hz) |
| LDP-1A-I | 1 | 6 | 87 | 5.25 | 1/4″ | – | 110 | 15X36 | Single Phase or 3Phase |
| LDP-2A-I | 2 | 7 | 101 | 8.25 | 1/4″ | 1/2″ | 200 | 18X42 | Single Phase or 3Phase |
| LDP-2A-V | 2 | 7 | 101 | 8.25 | 1/4″ | 1/2″ | 200 | 18X42 | Single Phase or 3Phase |
| LDP-3A-V | 3 | 9 | 130 | 9.25 | 1/4″ | 1/2″ | 200 | 18X42 | Single Phase or 3Phase |
| Model | Motor Power | Working Pressure | Free Air Flow | Valve-1 | Valve-2 | Tank Size | Electricity | ||
|---|---|---|---|---|---|---|---|---|---|
| 50Hz | Hp | Bar g | Psi g | cfm | DN | DN | in Ltr | in Inches | (V/ph/Hz) |
| LTP-3A | 3 | 12 | 174 | 9.5 | 1/4″ | 1/2″ | 220 | 18X48 | Single Phase or 3Phase |
| LTP-5A | 5 | 12 | 174 | 17 | 1/4″ | 1/2″ | 220 | 18X48 | 3Phase |
| LTP-7.5A | 7.5 | 12 | 174 | 28 | 1/4″ | 1/2″ | 300 | 18X58 | 3Phase |
| LTP-10A | 10 | 12 | 174 | 34 | 1/4″ | 1/2″ | 300 | 18X58 | 3Phase |
Flexible Configurations
Loitha piston compressors are available in multiple configurations to meet diverse industrial needs:
- Base-mounted units
- Tank-mounted (receiver-mounted) compressors
- Trolley-mounted portable systems
- Complete air systems with dryers & control panels
Applications Across Industries
Loitha Reciprocating Air Compressors are widely used in:
- Automotive Workshops
- Manufacturing & Engineering Units
- Construction Sites
- Textile Industry
- Food Processing
Why Choose Loitha Piston Air Compressors?
- Proven and reliable technology
- Cost-effective compressed air solution
- Wide range of models and configurations
- Strong service and support network
- Exported to 45+ countries
- Designed for Indian and global industrial conditions
Technical Range Overview
- Power Range: 0.55 kW to 15 kW (Standard Models)
- Pressure Range: Up to 30 Bar (Application Specific)
- Configuration: Single-stage / Two-stage
- Lubrication: Oil-lubricated & Oil-free options available
Dependable Performance, Every Day
When your operations depend on reliable compressed air, Loitha Reciprocating (Piston) Air Compressors deliver unmatched durability, efficiency, and performance. Built to handle tough conditions and continuous use, they are the ideal solution for both small workshops and large industrial setups.
Loitha – Leading Oil Free Air Compressor Manufacturer in India
Loitha stands among the top compressor manufacturers in India, delivering advanced oil-free rotary screw compressors comparable with global brands. With strong air technologies and a commitment to quality standards, we provide compressed air systems that combine availability, reliability, and reduced cost of ownership.
Whether you’re searching for oil-free air compressors at the latest price or need a customized air solution, Loitha’s oil-free screw air compressor range is designed for industrial excellence.
